Wideband AFR Gauge Suggestions

Discussion in 'Audio, Video & Electronic Modifications' started by Dookie, Jun 23, 2009.

  1. Dookie

    Dookie Foe twenny sics

    Messages:
    2,884
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    Baton Rouge, Louisiana
    Lemme have em...post pics, mounting, ease of install, usefulness, value, Dashhawk compatible or JYO on the offering out there.

    Last edited: Jun 23, 2009
  2. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    Too broad of a question Kyle.

    What are your current gauge needs and what do you expect them to be in the near future? and what are your criteria for monitoring and your criteria for logging?

    Let me take a guess for you.
    Integrated logging. If you want to get your widebands and OBDII parameters captured in the same log then you've narrowed down the options. Will you want to log and monitor with a dash/installed display or are you ok with doing that with a PC in the car. If it's the former then you're pretty much down to logging with a DashDAQ or Trinity. Both of those will accept a couple of analog inputs and/or also have drivers to accept the serial input from selected mfg gauges. For example, both will accept the serial MTS protocol/signal from Innovate systems, Zeitronics, etc. All your gauges (or at least 5) can be daisy chained onto the serial link and fed into the scan gauge where they will look like separate signals. Otherwise you'll be limited to the number of analog inputs.

    The DashDAQ will report the Chrysler specific PIDS. I have yet to get an answer about the Trinity. Naturally they both support the full set of Generic OBDII pids.

    As far as I know DashHawk failed to integrate anyones wideband input. You have to log and monitor them separately which is a whole lot less useful.

    So... are you strictly looking for a stand alone, single AFR gauge? to use alongside the DashHawk you have now?
    or are you maybe going to add some others like EGT, or boost or fuel pressure, etc.

    Personally I'm using a PLX AFR with the DM-100 display in the sunglasses holder and analog input into my DashDAQ. heh, I found my pics!

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

  3. TALON

    TALON SRTV8

    Messages:
    901
    Likes Received:
    0
    Joined:
    Nov 9, 2007
    Location:
    Antioch,Ca.
    I'm using the Zeitronix Zt-2 mounted in the sunglass holder.

    [​IMG]

    Ken

  4. LegMaker

    LegMaker LMI - LegMakerIntakes

    Messages:
    10,483
    Likes Received:
    0
    Joined:
    Oct 25, 2007
    Location:
    orlando
    dave and ken are all fancy and techno looking......lol

    i am plain and simple with the AEM a/f gauge and boost gauge. simple two pod pillar from rpmoutlet.....

    fairly simple install, very good on the pricing, and simple to use.

    [​IMG]

  5. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    ...and where is your EGT gauge going? expandability is always a consideration.

  6. TALON

    TALON SRTV8

    Messages:
    901
    Likes Received:
    0
    Joined:
    Nov 9, 2007
    Location:
    Antioch,Ca.
    I went to the sunglass holder because my "A" pillar pod was already being used.

    [​IMG]

    Ken

  7. NYCSRTATE

    NYCSRTATE Maximus Want 2 Go Fastius

    Messages:
    2,590
    Likes Received:
    0
    Joined:
    Nov 10, 2007
    Location:
    City Thats Never Sleeps
  8. Cam

    Cam Management up n smoke

    Messages:
    2,693
    Likes Received:
    0
    Joined:
    Nov 15, 2007
    Location:
    Riverside, CA

    That's cool Ken.

    And Dave, I've had the PLX unit for a while now. I really like it. I monitor AF, EGT, tranny temp and oil temp. Very handy.

    The pic isn't real good, but F-it, it's only Kyle asking :thongue2:

    This pic is looking down through the steering wheel, the position works real good, it's quick glance deal.

    [​IMG]

    And a little better look at the pod.

    [​IMG]

  9. 1fastsedan

    1fastsedan Destroyer of Warranties

    Messages:
    1,933
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    I have the Zetronix. The RPM input and logging makes matching it up to the Predator logs a breeze.

  10. Hemissary

    Hemissary Cogito Ergo Zooom

    Messages:
    55
    Likes Received:
    0
    Joined:
    Feb 15, 2008
    Location:
    Calgary, Alberta
  11. SMosher

    SMosher Silver Supporting Members

    Messages:
    420
    Likes Received:
    0
    Joined:
    Mar 21, 2008
    Location:
    Modesto CA
    Very kewl location :)



  12. Dookie

    Dookie Foe twenny sics

    Messages:
    2,884
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    Baton Rouge, Louisiana
    Thanks for all the responses guys...Now I just have to decide...once I do and get it installed, I'll post some pics...Thanks again.

  13. TALON

    TALON SRTV8

    Messages:
    901
    Likes Received:
    0
    Joined:
    Nov 9, 2007
    Location:
    Antioch,Ca.
    UPDATE!!!

    I've just added the DashDAQ to my Zeitronix Zt-2.

    Many different screens to choose from, and if you don't like what you see, you can make your own skins.

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    Ken
    [​IMG]

  14. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    haha, good choice Ken. You do know that the DashDAQ will read transmission fluid temp if you got the Chrysler specific license.

  15. TALON

    TALON SRTV8

    Messages:
    901
    Likes Received:
    0
    Joined:
    Nov 9, 2007
    Location:
    Antioch,Ca.
    Thanks, and yes, but I think it's crazy that DREW charges $95 for the feature.

    Ken

  16. StevoSRT

    StevoSRT Moderator

    Messages:
    19,139
    Likes Received:
    2
    Joined:
    Nov 6, 2007
    I have a Autometer NV A/F gauge...I mainly got it cause it matchs the color of the gauges pretty good lol

  17. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    Yea, it is kind of a shock since it's not the norm. but then not many (if any?) scanners support those PIDs. DashHawk supports a few and I'm not sure that Diablo supports any over the generic OBDII ones.

  18. SRTLUVR

    SRTLUVR Detailing "Go-to" Guy

    Messages:
    3,018
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    Birmingham, AL
    The DashDaq is cool as shit. How much, & where do you get them??

  19. TALON

    TALON SRTV8

    Messages:
    901
    Likes Received:
    0
    Joined:
    Nov 9, 2007
    Location:
    Antioch,Ca.
  20. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    Redfox-racing carries them
