PT airbox mod

Discussion in 'GT Cruisers' started by nevinsrt, Aug 24, 2008.

  1. nevinsrt

    nevinsrt Getaway driver for hire

    Messages:
    14,747
    Likes Received:
    0
    Joined:
    Nov 7, 2007
    Location:
    Albuquerque, NM
    here is the stock airbox as you see it in a GT Cruiser
    [​IMG]

    theres ways to improve on the stock airbox with out damaging it.

    first remove the side snorkle
    [​IMG]

    its a big restrictive piece
    [​IMG]

    [​IMG]

    next remove the tube running from the airbox to the turbo.
    [​IMG]

    if you look in side you will see that it bottle necks from 3in down to around 2in in side the tube. it would be better just to make your own replacement from parts found at Pepboys or Autozone.
    [​IMG]

    once you have the tube off you will see a white plastic piece.
    remove it i dont have the pic of the white plastic piece but
    when you look in side you will see it.
    [​IMG]


    removing those two pieces will help improve airflow and doesnt cost anything.
    but if you want to make the best of it. then make your own intake pipe.

    there are aftermarket intakes out there but this is for someone on a low budget.


    EDIT:
    the guess work on the piping has been taken out.

    new Air Box to Turbo pipe
    http://www.needswings.com/AMX---NeedsWings-Air-Intake-Pipe-Kit-amxPTintake.aspx

    Last edited: May 4, 2010
  2. loxmith

    loxmith Recovering Post Whore...

    Messages:
    16,163
    Likes Received:
    0
    Joined:
    Dec 3, 2007
    Location:
    Georgia Tech
    Thanks buddy...but the Mrs. cruiser doesn't have a stock box. some kind of Airraid intake system. I really should get a pic of the engine bay...

  3. nevinsrt

    nevinsrt Getaway driver for hire

    Messages:
    14,747
    Likes Received:
    0
    Joined:
    Nov 7, 2007
    Location:
    Albuquerque, NM
    awesome!!! those things are around $250

  4. Stretch

    Stretch Silver Supporting Members

    Messages:
    4,847
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    Eastlake Proper
    Boy, those stock ones sure are restrictive looking. seems like R&D would have done a little better than that.

  5. nevinsrt

    nevinsrt Getaway driver for hire

    Messages:
    14,747
    Likes Received:
    0
    Joined:
    Nov 7, 2007
    Location:
    Albuquerque, NM
    alot of people just remove those 2 pieces and replace the pipe with an alluminum pipe and just run them that way.

    I accually had enough left over pieces from my wife old Cavalier intake that i just reused everthing and made a new one.

  6. CHARGERFORCE

    CHARGERFORCE New Member

    Messages:
    21
    Likes Received:
    0
    Joined:
    Dec 10, 2008
    cool im going to do that once it warmer out and my car works lol

  7. TNCHARGER

    TNCHARGER Moderator

    Messages:
    4,000
    Likes Received:
    0
    Joined:
    Oct 15, 2007
    Location:
    East TN
    Innovative....:thumb3:

  8. StillANeon

    StillANeon Full Access Member

    Messages:
    968
    Likes Received:
    0
    Joined:
    Dec 20, 2007
    Location:
    Kansas
    Curious, that big restrictive piece that goes into the fender. Doesn't that channel cold air from the fender well?

    How do you remove the white plastic piece in there?
    Just break it out? I see the top portion easily snaps out.
    Edit: I just broke it out :lol:
    [​IMG]

    I want to do a boost leak test but I would hate the break something. In your pictures it looks like that line stays attached to the bottom near the turbo. Its a PITA to pull off lol.
    [​IMG]

    How does the lower portion of the airbox come out? Does the battery need to come out to get that out?

    Last edited: Jan 19, 2014
  9. nevinsrt

    nevinsrt Getaway driver for hire

    Messages:
    14,747
    Likes Received:
    0
    Joined:
    Nov 7, 2007
    Location:
    Albuquerque, NM
    Yeah i broke off my white resonator piece too and threw it away before i made this thread.

    Some advise. You will break some lines. their plastic and get brittle. buy some hoses and vacume Tees so when they break you have them on hand to repair or replace.

    That 4 way with that yellow circle when i removed mine i replaced that whole pipe and vacume hose with an aluminum pipe and used a 3/8s bolt (or equivalnt size) to plug up that hold and ziped tied it so it wouldnt leak. I later replaced that bulky 4way with a 3way vacume tee to clean it up.

    As for the snorkle, you can leave it or you can remove it. I've been in the fendor and there isnt much room its pulling cool/cold air from so i removed mine to get what air i could.

  10. nevinsrt

    nevinsrt Getaway driver for hire

    Messages:
    14,747
    Likes Received:
    0
    Joined:
    Nov 7, 2007
    Location:
    Albuquerque, NM
    As for the bottom part of the air box. there should be some bolts holding it down. No the battery doesnt need to come out.
