My novice paint correction

Discussion in 'Detailing Tips and Tricks' started by CentralTexHemi, Nov 10, 2008.

  1. CentralTexHemi

    CentralTexHemi PUNISHER

    Messages:
    5,844
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Tejas
    Well I decided it was time the Jeep got a full paint correction procedure done and with a car show coming up I decided to get to it.

    I only have a Porter Cable 7424 and will more than likely move up to a forced directional Makita once I feel comfortable with the PC and spend some time with a pro. detailer who uses the Makita for his business before I use one myself.

    Here is basically what I use, Foamer with Gloss-It Shampoo, P21 tire gel (not pic), P21 TAW for engine and wheel wells, Gloss-It Extreme Cut, Gloss-It gloss activator(not pic), Gloss-It gloss finish polymer (not pic), Gloss-It gloss enhancer detail spray, PC 7424 with Orange CCS Lakewood 4-6" pads, Green Pads, White Pads (not pic), BlackFire Clay Bar-first and last time to use not impressed.

    [​IMG]

    I gave the Jeep a double wash with some DAWN (to remove old polish) in a seperate bucket
    [​IMG]

    But sprayed the wheels/tires with the Gloss-It shampoo, sprayed the wheel wells with the P21s TAW and rubbed that in and went back over it with the Gloss-It shampoo.
    [​IMG]

    Used my little tool to clean the lug nuts
    [​IMG]

    After washing the Jeep I spend a while drying it using compressed air to make sure all the water is out from around the door handles, window areas, etc.

    I then moved onto the clay bar process
    [​IMG]

    Pulled the Halogens lights out (dual 500W)
    [​IMG]

    And got busy accessing the paint and then started to tape off areas
    Nothing too major the clear mainly had light to med imperfections
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    [​IMG]


    Hooked up the PC and got started on the roof with a 4" orange pad with the extreme cut and then worked my way down and around

    Here are the results after the Gloss-It Extreme Cut and before using the polish activator and finish.

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    I probably got about an 80% correction done I really need a FD machine but I was very happy with the results, the hood and front end were a PITA and I gave up on them as it has PPG Ceramiclear clear coat and the PC just did not have the power to cut the clear.

    I cleaned up a few areas with water/isopropyl alcohol and the detail spray then placed a small amount of the gloss activator on and then applied the gloss finish and followed up with the Gloss enhancer detail spray. Here are pics the next day at the car show out in the sun.

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    People were so impressed with the work I had offers from 5 different car owners at the show to do theirs, LOL I only do this for fun at home but one Z06 owner and one GTO owner were very persuasive so I might just do it.

  2. 1bad4dr

    1bad4dr Mr. Meany

    Messages:
    19,670
    Likes Received:
    0
    Joined:
    Oct 10, 2007
    Location:
    Corn Country
    looks great Wade.

    Charge em an arm and a leg. lol

  3. CentralTexHemi

    CentralTexHemi PUNISHER

    Messages:
    5,844
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Tejas
    Oh I would I started at 7am and finished right at midnight with only stopping for lunch/dinner

  4. StevoSRT

    StevoSRT Moderator

    Messages:
    19,139
    Likes Received:
    2
    Joined:
    Nov 6, 2007
    daaaaaaaaayyyyyyyyyyyyyyyum......thats pretty hot right there....I wish i had a garage to make doing that worth the effort hahahaha

  5. Quick

    Quick Mgmt. - I can't help you

    Messages:
    7,549
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    San Jose, CA
    Nice! First off I wouldn't call that "light to med imperfections". Looked like it'd been through a sand storm... Second, I wouldn't call that novice work. That's pro all the way! What's the ceramiclear? Is that clear bra? or something more exotic.

  6. CentralTexHemi

    CentralTexHemi PUNISHER

    Messages:
    5,844
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Tejas
    Ceramiclear is a sprayed on PPG clear coat that is supposed to be more resistant to rock chips, etc. but its very hard to work with. My paint guy told me you only have 24 hours to sand and buff it before it dries perm.

  7. MADDOG

    MADDOG SRT Driver

    Messages:
    254
    Likes Received:
    0
    Joined:
    Nov 11, 2007
    Location:
    Oregon
    Very nice job!!! Mine needs a good correction for sure.

  8. CentralTexHemi

    CentralTexHemi PUNISHER

    Messages:
    5,844
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Tejas

    Thanks bud I am no where near what the pro's can do need alot more practice and a better polishing machine to cut down on the work and time. I was so sore when I went to bed, much props to guys who do this for a living.

    Last edited: Nov 10, 2008
  9. LegMaker

    LegMaker LMI - LegMakerIntakes

    Messages:
    10,483
    Likes Received:
    0
    Joined:
    Oct 25, 2007
    Location:
    orlando
    crap wade, i would give yourself a little more credit than "novice"!!! very well done my friend!!! if only i had the time and a pc to do my car!!! if yours is "minor imperfections", than mine must be MAJOR!!!! dahahahahahaa

  10. UN4GTBL

    UN4GTBL Full Access Member

    Messages:
    283
    Likes Received:
    0
    Joined:
    Sep 7, 2008
    Looks great!!!

  11. Richie Carbone

    Richie Carbone Full Access Member

    Messages:
    97
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Winter Garden, FL
    Very nice! You did an excellent job. :clapping::tip:

  12. NYCSRTATE

    NYCSRTATE Maximus Want 2 Go Fastius

    Messages:
    2,590
    Likes Received:
    0
    Joined:
    Nov 10, 2007
    Location:
    City Thats Never Sleeps
    Wade you may be as bad as me, but I do that every weekend LMAO!

    A question? Where did you get that lug hole cleaning tool???

  13. markus

    markus Silver Supporting Members

    Messages:
    7,534
    Likes Received:
    0
    Joined:
    Nov 16, 2007
    Location:
    Trashcanistan
    looks great brotha! my car looks like shit incarnate!

  14. CentralTexHemi

    CentralTexHemi PUNISHER

    Messages:
    5,844
    Likes Received:
    0
    Joined:
    Dec 19, 2007
    Location:
    Tejas
    I found it at Harbor Freight of all places

  15. TNCHARGER

    TNCHARGER Moderator

    Messages:
    4,000
    Likes Received:
    0
    Joined:
    Oct 15, 2007
    Location:
    East TN
    Dang..that is what you call ANAL in capital letters...great job..:dancinlock:
