My Magnacharger install

Discussion in 'Engine & Performance Modifications' started by cmn1, Jan 29, 2011.

  1. cmn1

    cmn1 SRT and SVT

    Messages:
    693
    Likes Received:
    0
    Joined:
    Dec 10, 2007
    Location:
    Addison, Il
    So for the past week after work I have been installing my kit in my garage. The kit is very well thought out and the directions are easy to follow. There were some things that weren't perfect but were easily remedied. I did not follow the directions in order due to being by myself and not being able to set the supercharger for that reason. I saved the super charger setting til last. DCSpecial(Dan) helped me set it and Ekaz(Eric) showed up I think to take it if it wasn't on the Jeep yet. LOL. I appreciated the help. I still have to load the new tune because we had some issues with the original sent tunebut that is being taken care of as I write. My install took a little longer because I needed to relocate my trans cooler and that added a bunch of extra steps behind the bumper. If you are wondering if you can do it and are somewhat mechanically inclined it can be done. The directions are very well written and with color photos to boot. Big thanks to Joel and Mark for being available late at night.

    Here are some pics from along the way.
    For use with my WERKS CAI
    [​IMG]

    The beginning.
    [​IMG]

    The middle.
    [​IMG]

    The pump install.
    [​IMG]

    More middle.
    [​IMG]
    [​IMG]

    Trans cooler relocated
    [​IMG]

    The underside since nobody ever shows this.
    [​IMG]

    The end give or take a few things
    [​IMG]
    [​IMG]
    [​IMG]

  2. 1bad4dr

    1bad4dr Mr. Meany

    Messages:
    19,670
    Likes Received:
    0
    Joined:
    Oct 10, 2007
    Location:
    Corn Country
    Great job, Chad.

    I LOVE the look of the S/C. Really does look OEM.

    NOW, go out and ENJOY that new found power. Learn to drive her all over again. :)

  3. HalV48

    HalV48 They Call Me Patron

    Messages:
    5,243
    Likes Received:
    0
    Joined:
    Oct 10, 2007
    Location:
    Chandler, Arizona
    Gee, everybody's getting blown except me.

    Thanks for sharing Chad.

  4. SRTLUVR

    SRTLUVR Detailing "Go-to" Guy

    Messages:
    3,018
    Likes Received:
    0
    Joined:
    Nov 6, 2007
    Location:
    Birmingham, AL
    Fooookin hell yes buddy!!!!!! :rockon:

  5. LegMaker

    LegMaker LMI - LegMakerIntakes

    Messages:
    10,483
    Likes Received:
    0
    Joined:
    Oct 25, 2007
    Location:
    orlando
    very nice......btw, where did you get the intake tube???

  6. Cam

    Cam Management up n smoke

    Messages:
    2,693
    Likes Received:
    0
    Joined:
    Nov 15, 2007
    Location:
    Riverside, CA
    Nice job Chad!.

  7. cmn1

    cmn1 SRT and SVT

    Messages:
    693
    Likes Received:
    0
    Joined:
    Dec 10, 2007
    Location:
    Addison, Il
    I am refraining til tomorrow. Had some tuning issues and some human error stuff but they are fixed now. Can't wait

    Do you have your car back yet?

    Thanks Chase.

    PM sent to make Hal happy. LOL

    Thanks Cam. It was quite a project but I took my time and got it done.

  8. Knuckles

    Knuckles New Member

    Messages:
    19
    Likes Received:
    0
    Joined:
    May 3, 2009
    Nice install Chad!!! Those guys at the Autobahn will not know what hit them on May 2nd:D

  9. cmn1

    cmn1 SRT and SVT

    Messages:
    693
    Likes Received:
    0
    Joined:
    Dec 10, 2007
    Location:
    Addison, Il
    You were right about that statement.

    A little update. I am on my fifth driving revision. Waiting for the next one. Everything has been good so far. Power comes on much quicker. Haven't had any issues but I have less than 200 miles since install.

  10. 1bad4dr

    1bad4dr Mr. Meany

    Messages:
    19,670
    Likes Received:
    0
    Joined:
    Oct 10, 2007
    Location:
    Corn Country
    :) It's a fun learning though.

  11. cmn1

    cmn1 SRT and SVT

    Messages:
    693
    Likes Received:
    0
    Joined:
    Dec 10, 2007
    Location:
    Addison, Il
    True.
