This is a very easy, hour and a half project. Tools needed. 21mm Deep Socket, Ratchet, and 4" Extension 3/4" Socket 5/16" Hex (Allen) Wrench Vise Grips Breaker Bar Torque Wrench 16mm Open end Wrench 15mm Open/Closed end Wrench Floor Jack Lug Wrench Floor Stands The Front End Links will require the 21mm Deep Socket, Ratchet, 4" Extension, Breaker Bar, and Vise Grips to remove the OEM end links. My suggestion would be to first break loose the mounting nut, then apply the Vise Grips in the picture shown below. Upper Vise Grip Position Lower position Once the mounting nuts are removed, simply take out the OEM End Links. Now, get the 5/16" Allen Wrench and 3/4" Socket and supplied bolts and nuts to install the new BWoody Front End Links. Next, removal of the rear OEM End Links. For this, you will need the 15mm and 16mm wrenches. Remove both the upper and lower bolts (be careful not to round the bolt and nut ends as you will need to reuse these. Replace with the BWoody rear End Links and your are finished. Here is the side by side of the Front End Links And the Rear End Links
thats what I'm saying .. it seems stupid to change the sways without changing the end links. You probably wont get the full use out of the sways with the movement happening in the end links no?
haha no love Anthony, except for Wiked below. lol And the install is very easy. Shouldn't take longer than an hour. haha Yea, HUGE difference. It tightened up the cornering (body roll) fairly well. I think upgrading the sway's as well is a KILLER combo and a must. Yea, I need to add the sways one day.
wow isnt this the 2nd time you posted this and still no credit to me for a few of the pics yes they made a big diff and also got rid of a few clunks i had
Ya.... but what color to get... too many choices! Red to match the new sways, black to blend in, or blue for the paint!?
Man. I can't believe I haven't done this yet either.......thanks for spending $250 for me Ron........
I feel partly responsible for this ... dont get the wrong ideas ... I'm not going to buy yours for you, but I should get at least a discount from BWoody! mine will be in early next week .. LOL fuckin How-To threads ..
